The maximum resolution of the PC ( D-sub) port is 1280x800.
Epson EH-TW5900 = Home Cinema 3010 with 2000 lumen and contrast ratio 20.000:1 1.6 x zoom keystone correction £999.00 1149 Euro get the flyer Epson EH-TW6000 = Home Cinema 3010 with 2200 lumen and contrast ratio 40.000:1 1.6 x zoom keystone correction 0.61-inch wide panel with MLA (D9.8, C2Fine, 12Bit)
Epson EH-TW9000 = Home Cinema 5010 / 6010 with 2400 lumen (measured 2300 lumen) and contrast ratio 200.000:1 also the usual 2.1:1 x zoom lens with manual optical lens shift LCD Size 0.74-inch wide panel with MLA (D9, C2 Fine, 12 bit, OD) - Super-resolution technology (2D mode) - 2D-to-3D conversion - motorized pixel alignment of the panels.
The difference between the Home Cinema 5010 and the Pro Cinema 6010 is that it includes ISF Calibration, an extra lamp, a ceiling mount, a third year of warranty, and a cable cover.
A wireless HD connection is also available for all models except the 5900. In Europe the white models all have WIHD except for the 5900.
All other models are black.
In Europe there will be also a Light Power Edition (filter in front of the lens) available. It reduces to measured 1600 lumen with a near perfect color spectrum.
Since the bigger models have an automatic lens cover this filter is for the big front ring. So instead of having a dust free lens you have now a dusty filter in front of a dust free lens.
I wonder what is so hard to redesign the sliding cine filter as a 2 step version to integrate this filter inside the projector.
Behold the totally cable free Epson ;)
The Epson 3D projector Lumens spec is achieved through Epson’s Virtual 480Hz Drive technology, which improves light output and brightness, including overall performance in unfavorable ambient lighting conditions and is combined with active-shutter 240Hz 3D glasses technology.
As a result, 3D pictures produced by the new panels are said to be 1.5 times brighter than those created by 240Hz models.
The Epson 3D projector should be significantly brighter than other 3D projectors in its class.
The TW6000 / 3010 features a contrast ratio of up to 40,000:1, also has two built-in 10-watt speakers. Its split screen mode permits users to watch two sources at once or watch TV and surf the Internet simultaneously. It ships with two pairs of 3D active-shutter glasses included in the price.
TW5900/TW6000 420x360x124mm; 7kg - TW9000 480x395x140mm; 8,2kg
Deutschland/Österreich:
EH-TW5900: 1.149 Euro white 1.6x zoom keystone shift no glasses
EH-TW6000: 1.499 Euro black 1.6x zoom keystone shift 1 pair of glasses
EH-TW6000W: 1.799 Euro white 1.6x zoom keystone shift 1 pair of glasses
EH-TW9000: 2.871 Euro black 2.1x zoom lens shift 2 pair of glasses
EH-TW9000W: 3.202 Euro white 2.1x zoom lens shift 2 pair of glasses
Epson 3D EH-TW6000 / 3010
|
| Epson 3D TW6000 /3010 only digital shift (keystone) 1.6x short throw zoom lens 2 10W rear speakers ca. 1500 Euro - £1349 - $1600 incl 1 3D glasses The 3010e ca. 1800 Euro $ adds a WirelessHD transmitter capable of transmitting uncompressed HD video. |
Projection System: Epson 3LCD, 3-chip optical engineNative Resolution: 1080p (1920 x 1080)
Brightness: 2200 lumens
- A true cinematic experience — 2D & 3D Full HD 1080p technology puts you right in the middle of exciting, lifelike adventures
- Super bright and saturated colors — 2200 lumens color and white light output1, and contrast ratio of up to 40,000:1
- Advanced 3D technology — Epson's Bright 3D Drive for enhanced brightness in 3D mode
- Rich, vibrant color and reliable performance — 3LCD, 3-chip technology
- Captivating sound — two built-in 10 W stereo speakers for amazing audio
- Sleek design — fits in any setting
- Split screen feature (not available in 3D mode) — project two images side-by-side from two different sources
- Outstanding support — two-year limited warranty; two-business-day replacement with free shipping
- 3D glasses — includes two pair of active shutter 3D glasses
MODEL EH-TW6000/3010
Projection System RGB liquid crystal shutter projection system
Projection Method Front / Rear / Ceiling mount
Specification of Main Parts LCD Size 0.61-inch wide panel with MLA (D9.8, C2Fine, 12Bit)
Driving Method Poly-silicon TFT active matrix
Pixel Number 2073600 dots (1920 x 1080) x 3
Native Resolution 1080p
Aspect Ratio 16:9
Pixel Arrangement Cross stripe
Refresh Rate 192 - 240Hz (2D) 400 - 480Hz (3D)
Projection Lens Type Optical Zoom (Manual) / Focus (Manual)
F-Number 1.51-1.99
Focal Length 18.2mm-29.2mm
Zoom Ratio 1-1.6
Throw ratio 1,32-2,15-1
Lamp Type 230 W UHE (E-TORL)
Life 4000 hours (Power consumption: Normal)
5000 hours (Power consumption: ECO)
Optical System Dichroic mirror separation & prism combine method
Screen Size (Projected Distance) 30" to 300" [0.87 to 8.9 m] (Zoom:Wide)
30" to 300" [1.42 to 14.5 m] (Zoom:Tele)
Standard size: 100" screen 2.95 - 4.8 m
Throw ratio: 1.32 (Zoom:Wide), 2.15 (Zoom:Tele)
Offset 10:-0.03
Light Output (Brightness) Normal 2200 lm
(Color mode: Dynamic, Zoom: Wide)
Color Light Output (Color Brightness) 2200 lm
(Color mode: Dynamic, Zoom: Wide,Auto iris: Off)
Contrast 2D 40000:1
(Color mode: Dynamic, Power consumption: Normal, Zoom: Wide
* Contrast = 100% White (Iris: Open) / Black (Iris: Close)
Color Reproduction
Full-color (1073.74 million colors )
Color Temperature Optical 6844 K, duv: 0.024
Coordinate of Center Color W x = 0.302, y = 0.360
R x = 0.658, y = 0.338
G x = 0.334, y = 0.610
B x = 0.145, y = 0.042
Video Quality Interlace-Progressive conversion, 3D Y/C separation, Noise reduction
Internal Speaker Sound Output Stereo:10W x 2
Dimension 8ohme , φ2inch
Function A/V Mute, Auto Color Optimizse, Split Screen
Color Processing Full 10bit(Digital Only)
Color Mode Auto, Dynamic, Living room, Natural, Cinema, 3D Dynamic, 3D Cinema
Built-in 3D IR Emitter Front, 5m
Adjustment Function Projector / Remote Control Brightness / Contrast / Tint / Saturation / Input signal / Defalt position / Menu disappear etc.
Foot Adjuster Front-side
Tilt Angle 0 to 10.0 degrees
Advanced Sharpness Adjustment Consists of the following 4 adjustments and provides the detailed adjustments.
Thin line Enhancement / Thick line Enhancement / V-line Enhancement / H-line Enhancement
Customized Gamma Adjustment 9 points of gamma curve are adjustable
Six-Axis Color Adjustment Hue / Saturation / Brightness for each of RGBCMY are adjustable
Contrast Enhancement N/A
Super-resolution N/A
3D Display On / Off
2D-3D Conversion N/A
3D Format Auto / Side by Side / Top & Bottom / 2D
3D IR Emitter Select which to use Built-in Emitter or External Emitter
Color Gamut N/A
Color Isolation N/A
Brightness Control Normal / ECO
(Default normal: Dynamic / Living room /3D_Dynamic / 3D_Cinema , Default ECO: Natural / Cinema
Depends on environmental brightness:Auto)
Epson Cinema Filter N/A
Auto Iris Controlled automatically adjusting to video source
(User selectable High Speed/Normal/Off on OSD)
Aspect Mode Auto / Normal / Full / Zoom / Wide
(Auto aspect works only when PAL 576i comes in.)
Progressive Film/Auto, Video, Off
8:8 pull down
(1080/24p Capability) On / Off
(Default on, HDMI & Component input)
Epson Super White Controlled automatically adjusting to video source
(Available at Natural / Cinema, User selectable On/Off on OSD)
HDMI Video Range Auto / Normal / Expanded
HDMI Link HDMI link: On / Off
Audio Output selection: Projector / AV System
Power-on link from connected device to projector: On / Off
Power-on link from projector to connected device: On / Off
Power-off link from projector to connected device: On / Off
Overscan Auto / Off / 2% / 4% / 6% / 8%
(Default Off: HDMI 720p / 1080i / 1080p, Default 8%: Others signals, Auto scaling appears only when HDMI is selected.)
Keystone Correction Yes
Vertical : -30 to +30 degrees
Horizontal: -30 to +30 degrees (Slide Bar)
Auto Keystone Correction Yes
Vertical : -30 to +30 degrees
( Zoom: Tele) )
Operation Panel Protected Function Key-lock, Child-lock
Illumination On / Off
Memory Memory 1 - 10
(It is possible to edit memory names.)
Analog RGB I/O Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Signal Type Separate signal
Video Signal Analog (0.7 Vp-p,75 ohm / Mac 0.714 Vp-p, 75 ohm)
Sync. Signal Separate (positive & negative, bi-polarity 2-5 Vp-p)/
Composite (positive & negative, bi-polarity 2-5 Vp-p)
Input Terminal Video D-sub 15pin (Blue-molding) x 1
Video I/O Component Input Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Video Standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Signal Component Video (Analog Y level 0.7 V 75 ohm / Cr Cb level +/-0.35 V 75 ohm/ sync.negative 0.3 V or 3-state +/-0.3 V on Y)
Input Terminal Video RCA x 3 (Red / Green / Blue)
Composit / S Input Display Performance Composite input: 560 TV-Line (Depend on observation of the multi-burst pattern)
Input Signal Video Standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
Video Signal Composite Video (1.0 Vp-p / Sync.negative, 75 ohm)
Input Terminal Video Composite Video: RCA (Yellow) x 1
HDMI
(Cable) Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Feature DeepColor, 3D ,CEC
Video Standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Signal TMDS (TMDS is signal for HDMI.)
Audio Signal Linear PCM
Input Terminal Video HDMI x 2
HDCP Yes
HDMI
(Wierless) Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Feature DeepColor (Except 1080p50/60, 1080p24FP, 720p50/60FP), 3D , CEC
Video Standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Signal TMDS (TMDS is signal for HDMI.)
Audio Signal Linear PCM
Input Terminal Video HDMI x 1
HDCP Yes
Audio I/O Analog input Signal 500 mVrms / 47 k-ohm
Terminal RCA (White) x 1 (Left ch)
RCA (Red) x 1 (Right ch)
(in common with Analog RGB Audio terminal)
Control I/O Serial I/O I/O Terminal D-sub 9pin x 1
I/O Signal RS-232C
External 3D IR Output Terminal RJ45 x 1
Output Signal On: 17 V DC, 100 mA max.
Off: 0 V
Memory I/O USB I/O I/O Terminal TypeA x1 (for Photo Viewer)
I/O Speed USB TypeA Ver 2.0
Wierless HD Specification Supported mode Beam Forming
Logo Certification Wireless HD 1.0b
Frequency 60GHz Band (QPSK, 16-QAM, BPSK)
Direct Power On Yes
Start-up Period 21 seconds
Warm-up period: 30 seconds
Cool-down Period 5 seconds
Theft Proof Kensington Lock Yes
Power Supply Voltage 100-240 V AC +/- 10% , 50/60 Hz
Power Consumption 220 - 240 V area
(Europe etc.) Lamp On
(Power consumption: Normal) 358 W
Lamp On
(Power consumption: ECO) 274W
Standby
(Network On) 6.3W
Standby
(Network Off) 0.35 W
Rated Voltage & Current (Except JAPAN) 100 - 240 V AC 50/60 Hz 3.7 - 1.7 A
Dimension Exclude Feet (W x H x D) 420 x 137.3 x 365 mm
Weight Approx. 13.67 ｌbs. / 6.2 kg
Fan Noise Power consumption: ECO 24 dB (Color mode: Cinema)
Compatible Standard Safety Europe Low Voltage Directive (2006/95/EC) (CE Marking)
Safety Germany German Equipment and Safety Law (GS Mark)
EMC Europe EMC directive (2004/108/EC) (CE Marking)
Supplied Accessories Power Cable 3 m, 3 Wire (Black)
Remote Control Stick type (Black)
Battery Alkaline, size R6 x 2
User's Manual Set attached
Cable Cover N/A
HDMI Cable Clamp x2
3D Glass x1
WirelessHD Transmitter Set N/A
Mid Oktober
Epson 3010 user manual download
For Europe the will be a cheaper model also, the EH-TW5900 with 20,000:1 contrast ratio, 2000 lumens. No glasses included.
Epson 3D EH-TW9000 = 5010 / 6010
|
- A true theater experience — 2D & 3D full HD 1080p technology puts you right in the middle of exciting, lifelike adventures
- 2D-to-3D conversion — easily transform 2D images to spectacular 3D
- Astounding brightness — 2400 lumens color and white light output
- Advanced 3D technology — Epson's Bright 3D Drive for enhanced brightness in 3D mode
- Exquisite detail — up to 200,000:1 contrast ratio, Super-resolution technology (2D mode) and superior processing for the most discerning AV enthusiasts
- Rich, vibrant color and reliable performance — 3LCD, 3-chip technology
- Accurate and exceptional picture quality — built-in cinema filter and THX certification (pending)
- FineFrame technology — smoother frame interpolation and sharper video quality (2D mode)
- Two anamorphic lens modes (stretch and squeeze) — enables 2.35:1 anamorphic viewing without an external processor1
- Outstanding installation flexibility with maximum image quality — Fujinon OptiCinema lens (2.1x zoom ratio) and a manual lens shift of up to 96.3% vertical and up to 47.1% horizontal
- 6010 only Optimum output in any environment — ISF calibration enables you to customize specific settings
- Split screen feature (not available in 3D mode) — project two images side-by-side from two different sources
- 3D glasses — includes two pairs of active shutter 3D glasses
- 6010 only Also includes — spare lamp, cable cover and mount
- Outstanding support — three-year limited warranty; next-business-day shipping service
Projection System RGB liquid crystal shutter projection system
Projection Method Front / Rear / Ceiling mount
Specification of Main Parts LCD Size 0.74-inch wide panel with MLA (D9, C2 Fine, 12 bit, OD)
Driving Method Poly-silicon TFT active matrix
Pixel Number 2073600 dots (1920 x 1080) x 3
Native Resolution 1080p
Aspect Ratio 16:9
Pixel Arrangement Cross stripe
Refresh Rate 96 Hz - 120 Hz (2D)
400 Hz - 480 Hz (3D)
Projection Lens Type Optical zoom (Manual) / Focus (Manual)
F-Number 2.0 - 3.17
Focal Length 22.5 mm - 47.2 mm
Zoom Ratio 1 - 2.1
Lens Cover Slide lens shutter (Powered)
Throw Ratio 1,34-2,87:1
Lamp Type 230 W UHE (E-TORL)
Life 4000 hours (Power consumption: Normal)
5000 hours (Power consumption: ECO)
Optical System Dichroic mirror separation & prism combine method
Screen Size (Projected Distance) 30" to 300" [0.87 to 9.03 m] (Zoom: Wide)
30" to 300" [1.88 to 19.15 m] (Zoom: Tele)
Standard size: 100" screen 2.98 - 6.36 m
Throw ratio: 1.34 (Zoom: Wide), 2.87 (Zoom: Tele)
Lens Shift Range Vertical: -96.3% to +96.3% (H Center, Manual) ; Horizontal: -47.1% to +47.1% (V Center, Manual)
Light Output (Brightness) 2D Normal 2400 lm (Color mode: Dynamic, Zoom: Wide, Lens shift: V 5:5 / H Center)
Color Light Output (Color Brightness) 2400 lm (Color mode: Dynamic, Zoom: Wide, Lens shift: V 5:5 / H Center, Auto iris: Off)
Contrast 2D Auto iris: On 200000:1 (Color mode: Dynamic, Power consumption: Normal, Zoom: Wide, Lens shift: V 10:0 / H Center)
* Contrast = 100% White (Iris: Open) / Black (Iris: Close)
Color Reproduction Full-color (1073.74 million colors )
Color Temperature 6300 K, duv: 0.029 (Dynamic); 6500 K, duv: 0.003 (Cinema)
Video Quality Interlace-Progressive conversion, 3D Y/C separation, Noise reduction etc.
Function Blank
Color Processing Full 10bit (Partial 12bit)
Color Mode Dynamic, Living room, Natural, Cinema, 3D Dynamic, 3D Cinema
Built-in 3D IR Emitter Front, 5 m; Vertical: -10 to +10degrees
(Controlled automatically with Lens Shift)
Adjustment Function Projector / Remote Control Brightness / Contrast / Tint / Saturation / Input signal / Defalt position / Menu disappear etc.
Foot Adjuster Front-side
Tilt Angle 0 to +4 degrees
Advanced Sharpness Adjustment Consists of the following 4 adjustments and provides the detailed adjustments.
Thin line Enhancement / Thick line Enhancement / V-line Enhancement / H-line Enhancement
Customized Gamma Adjustment 9 points of gamma curve are adjustable
Six-Axis Color Adjustment Hue / Saturation / Brightness for each of RGBCMY are adjustable
Super-resolution 0 / 1 / 2 / 3 / 4 / 5
3D Display On / Off
2D-3D Conversion On / Off
3D Format Auto / Side by Side / Top & Bottom / 2D
3D IR Emitter Select which to use Built-in Emitter or External Emitter
Color Gamut HDTV / SMPTE-C / EBU
(User selectable in Natural mode.)
Color Isolation Color Isolation: R / G / B
Brightness Control Normal / ECO (Default normal: Dynamic / Living room / Natural / 3D Dynamic / 3D Cinema (Default ECO: Cinema)
Epson Cinema Filter Controlled automatically with color mode (On: Natural / Cinema Off: Dynamic / Living room / 3D Dynamic / 3D Cinema)
Auto Iris Controlled automatically adjusting to video source (User selectable High Speed / Normal / Off on OSD)
Aspect Mode Auto / Normal / Full / Zoom / Wide / Anamorphic Wide / Horiz.Squeeze
Progressive Film / Auto, Video, Off
Frame Interpolation High / Normal / Low / Off (2D Mode only)
8:8 pull down
(1080/24p) Auto
Epson Super White Controlled automatically adjusting to HDMI source
(Available at Natural / Cinema / 3D Cinema, User selectable On/Off on OSD)
HDMI Video Range Auto / Normal / Expanded
HDMI Link HDMI link: On / Off
Power-on link: Off / Bidirectional / Device -> PJ / PJ -> Device
Power-off link: On / Off
Overscan Auto / Off / 2% / 4% / 6% / 8%
(Default Off: HDMI 720p / 1080i / 1080p, Default 8%: Others signals, Auto scaling appears only when HDMI is selected.)
Keystone Correction Vertical: -30 to +30 degrees
Split Screen Yes
Operation Panel Protected Function Key-lock, Child-lock
Trigger Out Power / Anamorphic Wide / Off
Illumination On / Off
Memory Memory 1 - 10 (Memory Lock function is provided. It is possible to edit memory names unless memory is locked.)
Effective Scanning Frequency Range (Analog) Pixel Clock 13.5 MHz to 157.5 MHz
Horizontal 15.63 kHz to 91.15 kHz
Vertical 50 Hz to 85 Hz
Effective Scanning Frequency Range (Digital) Pixel Clock 13.5 MHz to 148.5 MHz
Horizontal 15.63 kHz to 67.5 kHz
Vertical 24 Hz, 50 Hz to 60 Hz
Analog RGB I/O Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Signal Type Separate signal
Video Signal Analog (0.7 Vp-p,75 ohm / Mac 0.714 Vp-p, 75 ohm)
Sync. Signal Separate (positive & negative, bi-polarity 2-5 Vp-p)/
Composite (positive & negative, bi-polarity 2-5 Vp-p)
Input Terminal Video D-sub 15pin (Blue-molding) x 1
Video I/O Component Input Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Video Standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Signal Component Video (Analog Y level 0.7 V 75 ohm / Cr Cb level +/-0.35 V 75 ohm/ sync.negative 0.3 V or 3-state +/-0.3 V on Y)
Input Terminal Video RCA x 3 (Red / Green / Blue)
Composit Input Display Performance Composite input: 560 TV-Line (Depend on observation of the multi-burst pattern)
Input Signal Video Standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
Video Signal Composite Video (1.0 Vp-p / Sync.negative, 75 ohm)
Input Terminal Video Composite Video: RCA (Yellow) x 1
HDMI
(Cable) Display Performance Native 1920 x 1080 dots (1080p)
Input Signal Feature DeepColor, CEC, 3D
Video Standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Signal TMDS (TMDS is signal for HDMI.)
Audio Signal N/A
Input Terminal Video HDMI x 2
HDCP Yes
HDMI
(Wierless) Display Performance Native N/A
Input Signal Feature N/A
Video Standard N/A
Video Signal N/A
Audio Signal N/A
Input Terminal Video N/A
HDCP N/A
Control I/O Serial I/O I/O Terminal D-sub 9pin x 1
I/O Signal RS-232C
Trigger Out Output Terminal 3.5 mm mini-jack x 1
Output Signal Power on: 12 V DC, 200 mA max. ; Power off: 0 V
External 3D IR Output Terminal RJ45 x 1
Output Signal On: 17 V DC, 100 mA max.; Off: 0 V
WierlessHD Specification Supported mode N/A
Logo Certification N/A
Frequency N/A
Power Supply Voltage 100-240 V AC +/- 10% , 50/60 Hz
Power Consumption 220 - 240 V area
(Europe etc.) Lamp On
(Power consumption: Normal) 348 W
Lamp On
(Power consumption: ECO) 263 W
Standby 0.37W
Dimension Maximum Dimension (W x H x D) 466 x 158 x 395 mm
Weight Approx. 8.3 kg
Fan Noise 22 dB (Color mode: Cinema)
Compatible Standard Safety Europe Low Voltage Directive (2006/95/EC) (CE Marking)
Germany German Equipment and Safety Law (GS Mark)
EMC Europe EMC directive (2004/108/EC) (CE Marking)
Supplied Accessories Power Cable 3 m, 3 Wire (Black)
Remote Control Stick type (Black)
Battery Alkaline, size R6 x 2
User's Manual Set attached
HDMI Cable Clamp x 2
3D Glasses x 2
WirelessHD Transmitter *1) N/A
End November
All the information regarding 3d effects are well informative.And accessories which are shown are also well.
ReplyDeleteInterior Designers
Projection Screen Company
https://setup-wireless-printer.com/hp-color-laserjet-pro-m452nw-wireless-driver-mac/
ReplyDelete
